PVC Solid Woven Flame-resistance Conveyor Belt
(Total 5 Products)
-
Unit Price:USD 28 / MeterBrand:Iron TowerMin. Order:100 MeterModel No:TT-T002Transportation:OceanPackaging:UV protection packaging clothSupply Ability:Month supply capacity of 50000 metersPlace of Origin:ChinaProductivity:Month supply capacity of 50000PVC1400S Solid Woven Conveyor Belt Core Specifications & Performance Standards Tensile Strength: Longitudinal: ≥1400 N/mm (Grade 8) Transverse: ≥350 N/mm. Elongation Rate: Longitudinal: ≥15% Transverse: ≥18%. Safety... -
Unit Price:USD 24 / MeterBrand:Iron TowerMin. Order:100 MeterModel No:TT-T003Transportation:OceanPackaging:UV protection packaging clothSupply Ability:Month supply capacity of 50000 metersPlace of Origin:ChinaProductivity:Month supply capacity of 50000PVC solid woven rubber conveyor belt 1. Terminology Clarification: PVC vs. PVG PVC Solid Woven Conveyor Belt: Feature a polyvinyl chloride (PVC) plastic cover. These belts are designed for dry conditions with maximum inclines of 16° and prioritize... -
Unit Price:USD 23 / MeterBrand:Iron TowerMin. Order:100 MeterModel No:TT-T005Transportation:OceanPackaging:UV protection packaging clothSupply Ability:Month supply capacity of 50000 metersPlace of Origin:ChinaProductivity:Month supply capacity of 50000PVC Solid Woven Conveyor Belt USAGE: PVC Solid Woven Flame-resistance Conveyor Belt are widely used in coal mine underground mining, transport and other occasions with fire retardant anti-static requirements, material conveying. Type of rubber... -
Unit Price:USD 25 / MeterBrand:Iron TowerMin. Order:100 MeterModel No:TT-T004Transportation:OceanPackaging:UV protection packaging clothSupply Ability:Month supply capacity of 50000 metersPlace of Origin:ChinaProductivity:Month supply capacity of 50000PVC Solid Woven Flame-resistance Conveyor Belt General Introduction The PVC2000S Solid Woven Conveyor Belt is a high-performance conveyor belt with excellent comprehensive properties, which is designed to meet the demanding requirements of modern... -
Unit Price:USD 24 / MeterMin. Order:100 MeterModel No:TT-T001PVC1000S Solid Woven Conveyor Belt General Introduction Structure Core Layer: The core of the PVC1000S is made of high-strength solid woven fabric, usually composed of polyester or nylon fibers. This integral woven structure provides the belt with...
PVC Solid Woven Flame-resistance Conveyor Belt
Core Features & Technical Advantages
1. Flame Resistance & Safety Compliance
-
Self-Extinguishing:
-
Passes ISO 340, EN 14973, and MSHA §18.65 flame propagation tests.
-
Zero flame spread beyond 250 mm after ignition removal.
-
-
Anti-Static:
-
Surface resistance ≤3 × 10⁹ Ω (ISO 284) – prevents spark generation.
-
-
Low Toxicity:
-
Halogen-free formulations available (reduced toxic fume emission).
-
2. Robust Solid Woven Construction
-
High-Tensile Fabric Core:
-
Strength range: 315–1,600 kN/m (ISO 283).
-
Minimal elongation (≤2% @ 10% of breaking strength).
-
-
PVC Fusion-Bonded Covers:
-
Top cover: 3.0–7.0 mm | Abrasion loss ≤120 mm³ (DIN 53516).
-
Bottom cover: 1.5–3.0 mm | Optimized for pulley grip.
-
3. Chemical & Environmental Resilience
-
Moisture/Mildew Proof: Ideal for humid environments.
-
Resists Oils, Grease & Mild Acids (per MT/T 914-2019).
-
Operating Temp.: -10°C to +80°C (heat-resistant variants: +110°C).
4. Economic Longevity
-
2–3× lifespan vs. rubber belts in damp/abrasive settings.
-
Non-delaminating Design: PVC fully penetrates fabric core.
Technical Specifications
| Parameter | Range | Standard |
|---|---|---|
| Tensile Strength | 315–1,600 kN/m | ISO 283 |
| Belt Width | 400–2,200 mm | DIN 22131 |
| Top Cover Thickness | 3.0–7.0 mm | AS 1330 |
| Abrasion Loss | ≤120 mm³ (DIN 53516) | ISO 4649 |
| Fire Safety | Flame retardant, anti-static | EN 14973, MSHA |
Certifications & Approvals
-
MSHA 30 CFR §18.65 (U.S. surface mines)
-
EN 14973 (EU industrial safety)
-
GB/T 7984-2013 (China flame-resistant belts)
-
AS 1330 (Australia/NZ)
-
DGMS Type-9 (India)
Key Applications
-
Surface Mining: Coal yards, aggregate processing
-
Industrial Plants: Power stations, cement factories
-
Warehousing & Logistics: Fire-safe material handling
-
Tunneling/Civil Engineering: Ventilation shafts, construction sites
-
Recycling Facilities: Conveying flammable waste
Competitive Benefits
✅ Cost-Effective Safety:
-
30% lower cost vs. PVG belts for moderate-risk zones.
✅ Easy Maintenance: -
Resists edge fraying; cleanable with industrial solvents.
✅ Customization: -
Cover Options: Standard, oil-resistant (NBR), UV-stabilized.
-
Profiles: Cleats (≤30° incline), flight attachments.
-
Accessories: Rip detectors, wear indicators.
PVC Solid Woven Flame-resistance Conveyor Belt
What is a PVC solid woven flame-resistance conveyor belt?
It is a type of conveyor belt made by impregnating and plasticizing a solid woven core composed of nylon or polyester filaments and cotton fibers with PVC paste The top and bottom covers are made of PVC, forming a fire-resistant conveying structure with a single-sided rubber thickness of at least 0.8 mm.
