Low Rolling Resistance Conveyor Belt
(Total 6 Products)
-
Unit Price:USD 36 / MeterMin. Order:100 MeterModel No:TT-Y006Energy saving low rolling resistance conveyor belt 1、Definition and Basic Principles Low rolling resistance conveyor belt is a specially designed conveyor belt, whose main feature is the ability to effectively reduce rolling resistance during... -
Unit Price:USD 37 / MeterMin. Order:100 MeterModel No:TT-Y005Efficient and low resistance special conveyor belt 1、Characteristics of rolling resistance Significantly reducing energy loss: The core feature of low rolling resistance conveyor belt is that their rolling resistance is significantly reduced... -
Unit Price:USD 37 / MeterMin. Order:100 MeterModel No:TT-Y004Intelligent low rolling resistance conveyor belt Low Rolling Resistance Conveyor Belt refer to conveyor belts that can significantly reduce the resistance when rolling on support rollers. The following is a detailed English introduction: Working... -
Unit Price:USD 37 / MeterMin. Order:100 MeterModel No:TT-Y003Efficiency and low energy conveyor belt 1、Low rolling resistance conveyor belt: This type of Low Rolling Resistance Conveyor Belt adopts special design and materials, which significantly reduces its rolling resistance. For example, in terms of... -
Unit Price:USD 40 / MeterMin. Order:100 MeterModel No:TT-Y002Low energy consumption and low wear conveyor belt Market prospects of low rolling resistance conveyor belts In terms of demand growth： Energy saving demand driven: Against the backdrop of global energy scarcity and increasingly strict... -
Unit Price:USD 37 / OthersMin. Order:100Model No:TT-Y001Environmentally Friendly Low Rolling Resistance Belt Product Details Introducing our cutting-edge Low Rolling Resistance Conveyor Belt — a revolutionary solution designed to enhance energy efficiency, reduce operational costs, and support...
Cut Energy Costs, Boost Sustainability
Engineered for industries prioritizing operational efficiency, our Low Rolling Resistance Conveyor Belt reduces energy consumption by 15–30% while maintaining peak performance. Utilizing advanced polymer compounds and optimized carcass design, it minimizes friction heat generation – translating to lower electricity bills and extended component life.
1、Core Technology & Design
-
Advanced Cover Compounds: Ethylene-propylene (EPDM) or specialty rubber blends with ultra-low hysteresis properties.
-
Optimized Carcass: Low-stretch synthetic fabrics (e.g., polyester-nylon) or steel cords engineered to reduce indentation resistance.
-
Dynamic Indentation Loss Control: Reinforced layers dissipate less energy under load vs. standard belts.
2、Key Benefits
| Feature | Impact |
|---|---|
| Energy Savings | Reduces drive motor power demand by ≥20% (proven in mining/cement applications). |
| Lower CO₂ Emissions | Directly supports sustainability goals; cuts carbon footprint per ton conveyed. |
| Extended Belt Life | Reduced heat buildup slows aging, cracks, and cover wear. |
| Reduced Maintenance | Less strain on idlers, pulleys, and drive systems lowers downtime costs. |
| Higher ROI | Energy savings typically offset belt cost within 12–18 months. |
3、Technical Highlights
-
Energy Efficiency: Meets ISO 21183-1 standards for rolling resistance testing.
-
Capacity: Handles loads up to 6,000 t/h (equivalent to conventional heavy-duty belts).
-
Widths: 800–2,400 mm (customizable).
-
Temperature Range: -40°C to 120°C (broader than standard rubber belts).
-
Certifications: MSHA, RMA Grade 1, and ISO 14001 (eco-design compliant).
4、Applications
Ideal for long-distance or high-volume operations where energy dominates OPEX:
-
Mining & Quarrying (iron ore, coal overburden)
-
Cement & Clinker Transport
-
Power Plants (coal/ash handling)
-
Port Terminal Loading Systems
-
Aggregate Processing
Low Rolling Resistance Conveyor Belt
What is a low rolling resistance conveyor belt?
A low rolling resistance conveyor belt is a type of conveyor belt designed to reduce the resistance generated when the belt rolls on rollers or pulleys. This is usually achieved by optimizing the material of the belt, its structure or surface characteristics, enabling it to move more smoothly and with less energy consumption.
What are the key components that affect the low rolling resistance performance?Performance
The bottom cover material of the belt is crucial. Materials with good elasticity and low hysteresis loss, such as special rubber compounds or polymer materials, can reduce indentation rolling resistance. The structure of the belt, like the thickness and layering of the bottom cover, as well as the quality and rotation flexibility of the rollers and pulleys that cooperate with the belt, also have a significant impact.
What are the main advantages in performance?
